Marine
An Overview of Hochiki's Marine Approved Ranges
Both ranges are based around the existing world-proven ESP and CDX ranges and have been approved for marine use by both Germanischer Lloyd and LPCB, to the MED approval scheme.
Ideal for use on ships, oil and gas platforms, wind farms and other similar applications the Hochiki Europe Marine Approved Range incorporates the same world proven reliability and quality as its land-based equivalents.
The M.E.D. 96/98/EC Directive is an initiative of the European Commission (EC) in the European Union (EU) set up with the intention to reduce costs for the end user by having a simplified classification model for marine approvals.
All approved and authorised products, including Hochiki's, are stored in the MarED database, which to date contains more than 35,000 datasets about products approved under the EU Marine Equipment Directive.
Products are strictly tested by a third party, such as Germanischer Lloyd or LPCB, for use in the marine environment before being granted an approval certificate.
Hochiki’s comprehensive ESP marine-approved Analogue Addressable range is suitable for even the most demanding applications and incorporates high performance sensors, a selection of input and output modules and ancillaries. All products use Hochiki’s high integrity communications link ‘ESP’ (Enhanced Systems Protocol) that’s at the heart of the ESP range.
Hochiki’s CDX marine-approved Conventional range offers solutions for most conventional marine fire detection applications and incorporates a range of smoke, heat and flame detectors and ancillaries.
Marine Approved
Hochiki's marine approved Intelligent and Conventional products have been specially designed for the harsh environments found at sea, tested to cope with vibration, sea water exposure and dusty atmospheres.
Learn moreIntelligent Products
ALN-ENM Smoke Sensor
The ALN-ENM incorporates Hochiki's newest High Performance Chamber Technology removing the need to use Ionisation Smoke Sensors in the majority of applications. This also allows the sensor threshold level to be increased, thereby improving the signal to noise ratio and reducing susceptibility to false alarms.
ATJ-ENM Heat Sensor
The ATJ-ENM incorporates a Variable Temperature heat element and a Rate Of Rise heat element, both of which are controlled from the Control Panel, allowing either thermal element or both elements simultaneously to be active in making the fire decision.
ACC-ENM Multi Sensor
Model ACC-ENM is a Multi-Sensor, which is fully compatible with Hochiki’s ESP Analogue Addressable Protocol, and incorporates a thermal element and high performance photoelectric smoke chamber. The ACC-ENM has three modes, which are controlled from the Control Panel, allowing either the optical element or thermal element or both elements to be active in making the fire decision.
CHQ Range
Intelligent Input/Output Modules. CHQ-DIM/M(SCI), a Marine Approved Dual Input Module designed to interface to a variety of inputs such as door contacts etc. CHQ-DRC/M(SCI), a Marine Approved Dual Relay Controller module designed to provide two general-purpose relay outputs. CHQ-DSC/M(SCI) is a Marine Approved Dual Sounder Controller, which has been designed to provide two sounder outputs.
HCP-E/M(SCI) Call Point
A Marine Approved Manual Call Point with integral short-circuit isolator, which is fully compatible with Hochiki's ESP analogue addressable protocol. The unit incorporates a bi-coloured LED, which will show amber when a short-circuit is present but will switch to red if the unit is activated.
Conventional Products
SOC-E3NM Smoke Detector
The SOC-E3NM incorporates Hochiki's unique High Performance photoelectric smoke chamber removing the need to use Ionisation Detectors in the majority of applications. An integral third terminal provides a remote indicator output.
DCD-AE3M Heat Detector
A Marine Approved Rate of Rise Heat Detector with a 60ºC fixed temperature element. The DCD-AE3M is ideal for use where medium ambient temperatures exist, such as drying rooms or where Smoke Detectors are unsuitable because of the presence of steam or cooking fumes such as in a kitchen/galley.
DCD-CE3M Heat Detector
A Marine Approved Rate of Rise Heat Detector with a 90ºC fixed temperature element. The DCD-CE3M is ideal for use where medium ambient temperatures exist, such as drying rooms or where Smoke Detectors are unsuitable because of the presence of steam or cooking fumes such as in a kitchen/galley.
DRD-EM Flame Detector
A Marine Approved IR Flame Detector designed for internal use to detect large flames. The detector fits the CDX Marine Approved standard mounting base (YBN-R/6M). The detection zone is a 90º cone and the detection range is up to and including 25 m.
MCP1A Manual Call Point
A Marine Approved Manual Call Point based upon the industry standard KAC world series housing. Supplied complete with SR-BACKBOX for surface mounting.
MBB-1 Marine Back Box
A Marine Approved Back Box providing a splash-proof, secure fixing for the Hochiki CDX and ESP Marine Approved Range of Detectors and their associated Bases. Can be installed on a variety of different fixing surfaces and supports four 20 mm glanded entries, for zone, or loop cabling access.
